TE Connectivity Y1363

Directional Antenna Yagi VHF - 136-150MHz, 7.1dB Gain

The TE Connectivity Y1363 is an External Antennas/TE 136 – 150 MHz three-element directional antenna. It offers 7.1 dB gain, 500 W power handling, and a direct N Female termination. Mounting hardware, including U-bolts, is included. The antenna is gold in color.

Key Features

• Frequency Range: 136-150 MHz - Operates within this VHF band.
• Antenna Type: Yagi - Designed for directional communication.
• Frequency Band: VHF - Operates in the VHF frequency band.
• Gain: 7.1 dB - Provides signal amplification.
• Maximum Power: 500 W - High power handling capability.
• RF Connectors: N Female - Standard RF connector type.
• Elements: 3 - Number of radiating elements.
• Weight: 3 lb - Total weight of the antenna.
• Length: 41.5 in - Physical length of the antenna.
• Horizontal Beamwidth: 72 deg - Angle of signal coverage horizontally.
• Vertical Beamwidth: 57 deg - Angle of signal coverage vertically.
• Maximum VSWR: 1.5:1 - Indicates efficient power transfer.
• Minimum Front Back Ratio: 17 dB - Directivity of the antenna.
• Lightning Protection: DC Ground - Protects against lightning strikes.
• Color/Finish: Gold - Aesthetic appearance.
• Mounting Hardware: Includes U-bolts - For easy installation.
• Maximum Rated Wind Velocity: 100 MPH - Withstands high winds.

Benefits

• Directional Communication: Yagi design for focused signal transmission and reception.
• High Power Handling: Supports up to 500 Watts.
• Durable Construction: Designed for reliable performance.
• Complete Installation: Includes mounting hardware (U-bolts) for easy setup.

Warranty

1-year manufacturer's warranty

Specifications

• Weight: 200gr
• Usage: Indoor & outdoor
