Technology
|
FDM
|
|
Build Volume
(W×D×H)
|
|
|
175*180*170mm
|
|
Dimensions
(W×D×H)
|
|
|
370*362*397mm
|
|
Net weight
(kg)
|
|
|
10.5
|
|
Printing Speed
|
|
≤500mm/s
|
|
Extruder Flow:
|
|
30mm³/s
|
|
Extruder Temp
|
|
≤300°C
|
|
Hotend (Included)
|
|
Brass Nozzle
hotend
|
|
|
Auxiliary Part Cooling Fan
|
|
|
✖
|
|
Chamber Temperature Control
|
|
|
✖
|
|
Chamber Circulation Fan
With Activated carbon air filter
|
|
|
✖
|
|
Screen
|
5.0 inch
|
4.3 inch
|
|
800*480 touch screen
|
480*272 touch screen
|
|
Seal print
|
Dryer Box + Desiccant
|
Optional
|
|
Connection Options
|
150M 2.4G Wi-Fi
USB Flash Drive/Ethernet Cable
|
150M 2.4G Wi-Fi
USB Flash Drive
|
|
Rated Power
|
|
|
350W
|
|
Recommended Filament
|
|
PLA
|
|
Compatible filament
|
|
ABS, ASA, PETG, TPU etc
|
|
Structure
|
CoreXY
|
|
Z Axis:
|
Double Z axis
|
|
X axis
|
|
Hardened Wear-resistant Carbon Fiber Rod
|
|
Firmware:
|
Klipper
|
|
Printing Acceleration:
|
20000mm/s²
|
|
Printing Accuracy:
|
±0.1 mm
|
|
Filament diameter:
|
1.75mm
|
|
Bed Leveling:
|
Automatic Leveling
|
|
Extruder transmission ratio
|
9.5:1
|
|
Hot end:
|
Ceramic Heating Core
|
|
Extruder:
|
High-flow Direct Drive Extruder
|
|
Nozzle diameter:
|
0.4mm (0.2,0.6,0.8mm Optional)
|
|
Hot bed temperature:
|
≤120℃
|
|
Printing Plate:
|
Double-Sided Flexible Magnetic HF Plate
|
|
Filament Detection:
|
Yes
|
|
Resonance Compensation:
|
Yes
|
|
Pressure Advance:
|
Yes
|
|
Voltage:
|
100-240VAC, 50/60Hz
|
|
Main Processor:
|
Cortex-A53,64-bit Processor
|
|
1.5Ghz,8G-EMMC,1G DDR3
|
|
Slicer:
|
QIDI Print and other third-party software, such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc.
|
|
Operating System:
|
Windows, MacOS, Linux
|
|
Assembled
|
Assembled and First Print within 10 minutes
|
